Χαρακτηριστικά |
Arrowhead
Rockdrill_S10
Max
Energy per Blow (Joules) |
250 |
Required Flow
(L/Min) |
14-30 |
Operating Pressure
(bar) |
120 |
Blows per
minute |
500-1300 |
Tool diameter
(mm) |
40 |
Overall Length
(mm) |
1180 |
Working Weight
(kg) |
75 |
Guarenteed Sound
Power (dB) |
112 |
Carrier Weight
(tonnes) |
0.7-1.5 |
Χαρακτηριστικά |
Arrowhead
Rockdrill_S20
Max
Energy per Blow (Joules) |
350 |
Required Flow
(L/Min) |
25-40 |
Operating Pressure
(bar) |
90 |
Blows per
minute |
450-1150 |
Tool diameter
(mm) |
45 |
Overall Length
(mm) |
1180 |
Working Weight
(kg) |
100 |
Guarenteed Sound
Power (dB) |
116 |
Carrier Weight
(tonnes) |
1.5-3.0 |
Χαρακτηριστικά |
Arrowhead
Rockdrill_S30
Max
Energy per Blow (Joules) |
400 |
Required Flow
(L/Min) |
30-45 |
Operating Pressure
(bar) |
110 |
Blows per
minute |
650-1150 |
Tool diameter
(mm) |
53 |
Overall Length
(mm) |
1300 |
Working Weight
(kg) |
135 |
Guarenteed Sound
Power (dB) |
117 |
Carrier Weight
(tonnes) |
2.0-4.0 |
Χαρακτηριστικά |
Arrowhead
Rockdrill_S40
Max
Energy per Blow (Joules) |
700 |
Required Flow
(L/Min) |
45-65 |
Operating Pressure
(bar) |
110 |
Blows per
minute |
450-1250 |
Tool diameter
(mm) |
65 |
Overall Length
(mm) |
1450 |
Working Weight
(kg) |
225 |
Guarenteed Sound
Power (dB) |
118 |
Carrier Weight
(tonnes) |
4.5-8.0 |
Χαρακτηριστικά |
Arrowhead
Rockdrill_S50
Max
Energy per Blow (Joules) |
800 |
Required Flow
(L/Min) |
55-90 |
Operating Pressure
(bar) |
110 |
Blows per
minute |
850-1350 |
Tool diameter
(mm) |
70 |
Overall Length
(mm) |
1500 |
Working Weight
(kg) |
270 |
Guarenteed Sound
Power (dB) |
118 |
Carrier Weight
(tonnes) |
4.5-8.0 |
Χαρακτηριστικά |
Arrowhead
Rockdrill_S60
Max
Energy per Blow (Joules) |
1100 |
Required Flow
(L/Min) |
65-100 |
Operating Pressure
(bar) |
120 |
Blows per
minute |
550-100 |
Tool diameter
(mm) |
75 |
Overall Length
(mm) |
1600 |
Working Weight
(kg) |
330 |
Guarenteed Sound
Power (dB) |
121 |
Carrier Weight
(tonnes) |
5.0-8.5 |
Χαρακτηριστικά |
